CNH DPA 5

Descriere

Dearborn Protocol Adapter 5 (prescurtat DPA 5)is designed to help manufacturers diagnostic the fault of trucks,trailers, buses and light commercial vehicles.It covers multiple systems and widely used, it's user friendly.Dearborn Protocol Adapter 5 is an proferssinal tool for the maintenance of the commercial vehicle manufacturers.It covering all critical systems, including engines,transmissions, brake warning device, comfort, safety, emissions, air suspension, trailer and maintenance,to provide in-depth functionality for each application. It is based on the DS tool technology,it can use for the following hardware platforms: PC, Pocket PC (PDA) or netbook (UMPC,also known as Ultra Mobile PC),and provide information update for customers by regularly upgraded the supporting software.

Se foloseste pentru urmatoarele modele:

1. VOLVO TRUCK: FM10, NH565, FH12, FM12, VHD, FH16, FM7, VN, WC, WG, WI, FH565, NH12, FL6,

FL7,FL10, FL12, NH525, WX, COMP04, FE, VHD, FH, FM, VM, FM9, F10, F12 , F16, NL10, NL12

2. VOLVO BUS: B10B, B10M, B10L, B10R, M10R, B12, B58, B6, B7R, OLYMPIAN,

SUPEROLY,B12B,B12M,B12R,B6R,B7L,B7R,B9L,B9R,B9S,B9TL,PREVH,PREVX,

3. MACK TRUCKS:V-MAC I,  V-MAC II,  V-MAC III,  V-MAC IV, Service Diagnostic

4. VOLVO CONSTRUCTION EQUIPMENT (CE):Wheel loader: L110E, L110F, L120E, L120F, L150E, L150F, L180E, L180F, L220E, L220F, L330E, L350F,L60E, L60F, L70E, L70F, L90E, L90F

Excavator: EC135B, EC140B, EC140C, EC160B, EC160C, EC180B, EC180C, EC210B, EC210C, EC235C, EC240B,EC240C, EC290B, EC290C, EC330B, EC330C, EC360B, EC360C, EC460B, EC460C, EC700C, EC700B, EC700C,ECR145C, ECR235C, ECR305C, EW140B, EW140C, EW145B, EW145C, EW160B, EW160C, EW180B, EW180C, EW200B,EW210C, FC2121C, FC2421C, FC2924C, FC3329C, PL4611

Articulated Hauler: A25D, A25E, A30D, A30E, A35D, A35E, A40D, A40E, T450D,
Grader: G710B, G720B, G726B, G730B, G740B, G746B, G780B, G930, G940, G946, G960 , G970, G976, G990

5. Navistar:  ALL Diamond Logic Builder (DLB) ServiceMaxx

 6. International: ALL Intune, MD32,

7. Freightliner:  ALL ServiceLink:cascadia,century,columbia,Coronado,classic,FLDSD,4900FA,4900SA,4900EX

Heavy-Duty Truck Diagnostic Engine:

1,Detroit Diesel Diagnostic Link (DDDL)
All DDEC VI equipped engines ,DD13,DD15,DD16,SERIES60,MBE4000,MBE900,and RS9, RSX9-A,RSX9-B, RSX9-R, RS10, RSX10 J1939 engine ,brake level for Series 2000 and 4000 Engines with USA and ISO firing order selection

  3126, 3406, 3306B, 3512C, C4.4,  C6.6  C7   C9  C11,  C132, Caterpillar (on high way engine for j1939) 3126, 3406, 3306B, 3512C, C4.4,  C6.6  C7   C9  C11,  C13

3,Cummins  INSITE7.6  insite7.5

4 - 3000 Series 6 - 3000 Series

Transmissions Brakes

1,Meritor WABCO toolbox

D and E Versions ,HABS, hpb, ESC, RSC, ECAS

2,Bendix® ACom Diagnostics

EC-17T, Generation 4 and 5, EC-30T, EC-60T (standard, premium and advanced), A-18T,MC-30T and the trailer antilock braking TABS-6 unit

3, Meritor ZF

4,Eaton Service Ranger

Vorad VS-400 Collision Warning System

Generation 2 Auto shift and Ultra shift Transmissions

Generation 3 Auto shift and Ultra shift Transmissions

Ultra Shift PLUS Transmissions

Lightning Transmissions

Hybrid Drivetrain Systems

5,Allison DOC

Allison1000,2000,3000,4000,

Cec2-5610,6610,8610,9610

CEC-MTB600,CLBT-V,HT700,B700

CEC-5,CEC-6,CEC-8,CEC9000

Support more software update !!!

PC-to-Vehicle Interfaces

*API Support:

*RP1210A/B

*J2534-2

*supports Windows xp and windows 7 32-bit and 64-bit and windows CE compliant

*Not all applications are included. If compatibility confirmation is required, more information is needed, or there are questions about an unlisted application, please contact your dealer,he will send E-mail to us,. A specialist will help you make the right choice.

Protocol Coverage:

CAN - J1939/CAN125/CAN250/CAN500/CAN1000

2nd CAN - J1939/CAN125/CAN250/CAN500/CAN1000

J1587/J1708 J1850 J2534

ISO 15765 (Diagnostic CAN)

ISO 14230 (KWP2000 over ISO9141) ALDL ATEC 160 (160 baud)

Software Interface Capability(Includes DVD)

Detroit Diesel Diagnostic Link 7.05

Caterpillar Electronic Technician 2010B

Cummins Insite 7.5 (windows XP and 7), inste 7.6 (only for windows 7)

International - ServiceMAXX Fleet Pro

Volvo PTT 2.40

VCADS /Elite Mack/Volvo 2.35

V-MAC Service Tools

Allison DOC? For PC-Service Tool - Protocols Supported: J1939, GMLAN, J1708/J1587, J1850, and

ATEC160

Allison DOC For PC (AED) - Protocols Supported: J1939

Allison DOC For Fleets (1000/2000) - Protocols Supported: J1939, J1850, GMLAN

Allison DOC For Fleets (3000/4000) - Protocols Supported: J1939, J1708/J1587

Eaton ServiceRanger 3.2

Bendix Acom

ZF-Meritor TransSoft / WABCO Toolbox

International ABS

International DLB

International Intune

International IPC v2.02

Perkins EST Diagnostic Interface 2010

Note:

1,Above all software has keygen or crack files in DVD

2, Next we will supply freely software of New Holland and Others

J2534 OEM Software (Does Not Include Software)

J2534 OEM Diagnostic Software Compatibility

The adapter you have purchased is provided with an SAE J2534-compliant interface (an SAE standard for electronic module reprogramming). The DPA5 should be able to reprogram all CAN/ISO15765 vehicles, GM vehicles using the J1850 Variable Pulse Width (VPW) protocol, or other vehicles using the DPA5 J2534-supported protocols (i.e. ISO9141/KWP2000).

The DPA5 has been validated against the following OEM and component applications:

Cummins PowerSpec

Freightliner ServiceLink

Vansco VMMS

Dana Diagnostic Tool

Mitchell1 RepairConnect

General Motors TIS2Web

Ford Module Programming (FMP)

Chrysler J2534 Application

Toyota TIS (Technical Information System)

Honda Service Express

Mazda Module Programming (MMP)

Kia J2534 KMA

Hyundai 2534 HMA

Volkswagen Erwin

Audi Erwin

Nissan J2534 ECU Reprogramming Software (NERS)

All J2534 reprogramming and diagnostic software packages that are J2534-1 and J2534-2 compliant and use a protocol supported by the DPA5 should work as long as the operating system is supported by the application. Note that not all OEMs have released J2534-2 compliant software.
